Bàn phím |
- KROSS 2-61: 61 phím (Có touch, Từ phím C2 – C7 (có thể điều chỉnh trong phạm vi [C1… C6] – [C3… C8]
- KROSS 2-88: 88 phím nặng, hệ phím NH (Natural Weighted Hammer Action) từ phím A0 – C8 (có thể điều chỉnh trong phạm vi [-A-1… C7] – [A1… C9])
* Bàn phím NH mang lại cảm giác chơi tương tự như của một cây đàn piano acoustic, với các nốt thấp nặng hơn và các nốt cao nhẹ hơn.
|
System |
EDS-i (Enhanced Definition Synthesis – integrated) |
Đa âm sắc |
120 voices (120 oscillators), single mode, 60 voices (60 oscillators), single mode |
Program |
Bộ tạo dao động
OSC1 (Đơn), OSC1 + 2 (Đôi): Đa âm thanh nổi được hỗ trợ 4 vùng velocity cho mỗi bộ oscillator, switching, crossfades và layers.
Bộ lọc Filter
- 4 loại cho mỗi filter routing (single, serial, parallel, 24 dB)
- 2 multi-mode filters cho mỗi voice (low pass, high pass, band pass, band reject)
Modulation
Cho mỗi tiếng, two envelope generators (Filter & Amp), two LFOs, two key tracking generators (Filter & Amp), and two AMS mixers. In addition, pitch EG, common LFO, and two common key tracking generators
|
Combination |
Timbres
- Up to 16 timbres, switchable via key zone or velocity zone, layer and crossfade supported, Tone Adjust function allows program settings to be offset
- Master Keyboard functionality
- These allow you to control external MIDI devices
|
Drumkits |
- Stereo and mono drumsamples. 4-way velocity switches with crossfades and adjustable crossfade shapes (Linear, Power, Layer).
|
The Number of Combinations/Programs/Drum Kits |
User Combinations
- 896 Combinations (384 Preload)
- User Programs
- 1280 Programs (768 Preload)
- User Drum Kits
- 58 Drum Kits (42 Preload)
- Preset Programs
- 265 Programs (256 GM2 Programs + 9 GM2 Drum Programs)
- * Total number of preload programs and preset programs:1,075 (810 preload programs, 265 preset programs
|
|
Number of memories:
128 (16 favorites × 8 banks)
|
Effect |
Insert effects
- 5 Insert Effects In-line processing; stereo in - stereo out.
- 2 Master Effects Two effects sends; stereo in - stereo out.
- Total of 134 types (select from 74 types for insert effects, 101 types of master effect 1, and 120 types for master effect 2)
- Dynamic Modulation
- Stereo side-chaining for limiter, gates, vocoders, etc.
|
|
Program mode
- One arpeggiator
- Two arpeggiators
- Two arpeggiators
- UP, DOWN, ALT1, ALT2, RANDOM
- Number of arpeggio patterns: 1280 (1024 preload)
Number of tones: 12 tones, Number of steps: up to 64 steps
|
Step sequencer |
Program mode: One unit Combination mode: Number of tones: 12 tones + 1 accent tone Sequencer mode: Number of steps: up to 64 steps * Can be created for each program, combination, and song.
|
Drum track |
Preset Patterns
- 772 patterns (Held in common with sequencer patterns.)
- Trigger Mode / Sync / Zone settings can be specified
|
Sequencer |
- 16MIDI Tracks
- Up to 128 songs
- 1/480
- 40.00–300.00 (1/100 BPM resolution)
- Up to 210,000 MIDI events
- Measure/Beat/Tick
- 16 preset/16 user template songs
- 772 patterns (shared with Drum Track patterns)
- KORG (KROSS) format, SMF format 0 and 1
|
Pad sample |
- 16 pads × 8 banks
Automatically saved on the SD card, and automatically loaded Up to four pads can play simultaneously
- PCM audio format 48 kHz/16-bit
- Up to approximately 14 seconds of stereo sample for each pad
- WAVE format, file name extension: .wav, 44.1 kHz/16-bit, 48 kHz/16-bit, stereo
* 44.1 kHz is automatically converted to 48 kHz/i>
- Waveform display editing functionality, start address and looping settings etc., normalize and other editing operations
|
Audio Recorder |
Recording Format
- PCM audio format 48kHz/16bit
- WAVE format (file name extension: wav ) 44.1kHz/16bit, 48kHz/16bit stereo
* 44.1 kHz is automatically converted to 48 kHz/i>
- WAVE format (file name extension: .wav) 48kHz/16bit, stereo
- Maximum continuous recording time: 3 hours
Depends on the SD card used; approximately 90 minutes per 1 GB
- Up to 200 songs
- Depends on the remaining capacity of the SD card
- Hour/Min/Sec
- 16 pads × 8 banks
Directly play back data from SD card Multiple pads cannot be played simultaneously
|
Media |
File, Utility, Information, additional PCM data management functionality
|
Controllers |
- Pitch bend wheel, Modulation wheel, SW1, SW2
- SELECT button, SWITCH button, KNOB1 knob, KNOB2 knob
- Pads 1–16
STEP SEQ ACTIVE button, Run button FAVORITES ACTIVE button SAMPLER ACTIVE button, HOLD button AUDIO PLAY ACTIVE button BANK LEDA/B/C/D/E/F/G/H (also used by Step sequencer, Favorite, Pad Sampler, and Pad Audio Play)
- DRUM TRACK button
- ARP button
- AUDIO REC button
|
|
- 240 × 64 pixel LCD backlight
Adjustable contrast (hold the EXIT button and turn the VALUE dial)
- CATEGORY dial, VALUE dial
- COMBI button, PROG button, SEQ (GLOBAL/MEDIA) button
- Cursor buttons, EXIT,ENTER, FUNCTION, PAGE-, PAGE+, MENU buttons
- REC button, START/STOP button
- LAYER/SPLIT button
- VOLUME knob
|
Control Inputs |
DAMPER (Supports piano-style half-damper pedals as well as standard foot switches)
ASSIGNABLE SWITCH
ASSIGNABLE PEDAL |
Line Inputs |
Connectors: 3.5 mm (1/8") stereo mini phone jack Input Impedance: 1.1k ohm Maximum Input Level: -42 to 0 dBu
|
Audio Outputs
|
HEADPHONE OUTPUT
Connectors: 3.5mm (1/8") stereo mini phone jack Output Impedance: 33 ohnm Maximum Level: 40 + 40 mW Controllable by the VOLUME knob
AUDIO OUTPUT
L/MONO, RConnectors: 6.3 mm (1/4") phone jacks(TS unbalanced) Output Impedance: 1.1k ohm stereo, 550 ohm mono (L/Mono only) Maximum Level: +10.0 dBu Load Impedance: 10k ohm or greater Controllable by the VOLUME knob
|
MIC IN
|
Connectors: 6.3 mm (1/4") phone jacks(TS unbalanced) Input Impedance: 33 ohm Maximum Input Level: -48 to -6dBu Phantom power or plug-in power is not supported.
|
MIDI
|
IN/OUT
Cổng kết nối chuẫn MIDI Kết nối USB đến MIDI sử dụng cổng USB ports.
|
USB
|
Type A (TO DEVICE) x 1: 2.0 Hi Speed
Type B (TO HOST) x 1: 2.0 Hi Speed
|
Power
|
AC adaptor power supply DC 9V
AA alkaline batteries x 6, or nickel-metal hydride batteries x 6 |
Power Consumption
|
5 W
|
Kích thước (W x D x H) |
KROSS2-61: 935 mm × 269 mm x 88 mm / 36.81" × 10.59" × 3.46" KROSS2-88:1,448 mm × 383 mm × 136 mm / 57.01" × 15.08" × 5.35" |
Trọng lượng |
KROSS2-61: 3.8 kg / 8.38 lbs (chưa bao gồm Pin) KROSS2-88: 12.3 kg / 27.12 lbs (chưa bao gồm Pin) |
Phụ kiện bao gồm |
Dây nguồn AC Power, sách HDSD nhanh |
